Star Building Wall Panels
From strong structural framing systems, to walls, roofs and compatible accessories, Star Building Systems' products have the advantage of factory assured quality and predictable performance. Each component is inspected throughout the manufacturing process to assure the highest standards of quality are maintained. Our manufacturing facilities are designed for maximum operating efficiency. That means the very best value for your money.
But value doesn't have to mean dull, unimaginative buildings. Sophisticated building systems can readily incorporate glass, wood, stucco, brick and stone to provide versatile structures that have dramatic effects, or blend with their surroundings. This versatility creates contemporary structures, ideally suited to project the right business image.
Star's building systems have proven themselves to be aesthetically pleasing while providing superior economy, energy efficiency and consistency of quality. That's why they are the number one choice for today's business needs.
PBR Wall Panels
The PBR panel's deep ribs create an even-shadowed appearance. The area between the major ribs is reinforced with minor ribs. PBR is one of the most economical panel systems and can be used for both roof and wall applications.
26 gauge (standard)
24 gauge
22 gauge
Length
45' maximum length is standard but longer lengths are available by special request
Dimensions
36" by 1 1/4"
Finish
Galvalume Plus®
Signature® 200 Colors
Signature® 300 Colors
Standard coated, zinc- aluminum cast head, or stainless steel head screw
Usage
Roof, wall, liner, mansard, and soffit panel applications
Limitations
Not designed for coverage over bar joist or to be used as rigid secondary; Five foot on center purlin spacing
Shadow-Rib Wall Panels
ShadowRib™ panel combines aesthetics, economics and function to bring definition to metal structures. This panel is a proven performer and a versatile tool to the designer. Structural strength in the Star Shadowrib panel is accomplished without sacrificing appearance or design flexibility. The fluted face creates distinctive shadow lines.
26 gauge (standard)
22 gauge
Length
Maximum recommended 40'
Dimensions
16" wide by 3" high
Finish
Galvalume Plus®
Signature® 200 Colors
Signature® 300 Colors
Concealed fastening system. Panels may be secured to the structure from outside the building with the Star Shadowrib concealed clip, or from inside the building with an expansion fastener. Both are positive fastening methods that create a secure interlock between panel and structure.
Usage
The Star Shadowrib panel can be used for walls, fascias and equipment screens. Apply the panel over light-gauge framing, purlins, girts, structural steel and joists.
AVP Wall Panels
The AVP panel produces a decorative shadow line creating a distinctive architectural effect with semi-concealed fasteners. Ribs are 1 1/8" deep and major corrugations spaced 12" on center. The net coverage of panel is 3'-0 ".
26 gauge
24 gauge
Length
Maximum recommended 40'. Longer lengths available on special order.
Dimensions
36" wide by 1 1 /8" deep
Finish
Galvalume Plus®
Signature® 200 Colors
Signature® 300 Colors
Fasteners
Various, depending on application structure.
Usage
Wall panel, liner panel, soffit panel, mansard panel face and back sheet.
Limitations
Installation may be difficult with very thick insulation.
